RA-912FBN Portable Hybrid Insulating Gas Comprehensive Analyzer
In the high-stakes world of electrical equipment maintenance and quality assurance, there’s no room for error—or emissions. Meet the RA-912FBN Portable Hybrid Insulating Gas Comprehensive Analyzer: the all-in-one, eco-conscious solution that redefines insulating gas analysis with unmatched accuracy, intelligence, and sustainability.
⚡All-Round Detection, One Device
Measure dew point, gas purity, and oxygen content—all in a single, seamless operation. With automatic flow adjustment and real-time data output, the Portable Hybrid Insulating Gas Comprehensive Analyzer delivers lab-grade reliability whether you’re on the factory floor or in the field.
⚡ Smart Technology, Simplified Workflow
- One-Button Operation: Launch full diagnostics with a single tap—no training required.
- Dual Dew Point Sensors: Switch between laser and capacitive technologies for optimal speed and precision.
- Dual Purity Methods: Choose Thermal Conductivity (TCD) or laser-based analysis to match your application needs.
⚡Zero SF6 Emissions. Full Compliance.
Engineered with integrated gas recharge and recovery systems, the RA-912FBN Portable Hybrid Insulating Gas Comprehensive Analyzer ensures zero SF6 release—protecting both your team and the planet. Plus, its dual-mode design (lab + field) provides real-time regulatory prompts, keeping every test aligned with global standards.
⚡ Built for Real-World Demands
From switchgear type testing in manufacturing plants to routine substation inspections, the Portable Hybrid Insulating Gas Analyzer is your trusted partner for gas quality evaluation—combining portability, ruggedness, and intelligent diagnostics in one compact unit.
Elevate your gas testing. Embrace sustainability without sacrificing performance.
Choose the RA-912FBN Portable Hybrid Insulating Gas Comprehensive Analyzer—where innovation meets responsibility in every measurement.
Equipment Parameters
|
Humidity Measurement |
|
|
Measurement Principle |
Capacitive、TDLAS |
|
Measurement Range |
(-60~20) ℃ |
|
Maximum Permissible Error |
Capacitive: ±2℃、TDLAS: ±0.5℃ |
|
Response Time |
Capacitive: Gas at 20℃: -60℃→-20℃ 6s[63%], 10s[90%] -20℃→-60℃ 45s[63%], 10min[90%] TDLAS: ≤30s |
|
Purity Measurement |
|
|
Measurement Principle |
Thermal Conductivity (TCD) 、NDIR |
|
Measurement Range |
(0~100) % |
|
Indication Error |
±0.5% (mol/mol) |
|
Response Time |
≤60s |
|
Oxygen Measurement |
|
|
Measurement Principle |
Electrochemical |
|
Measurement Range |
(0~1) % |
|
Indication Error |
±0.05% (mol/mol) |
|
Response Time |
≤60s |
|
System Parameters |
|
|
Gas Handling |
Recharge/Recovery Optional |
|
Communication Interface |
USB/Bluetooth/WiFi/4G Optional |
|
Power Supply |
Lithium Battery, Adapter (100~240) VAC, 50/60 Hz |
|
Printing Function |
Dot Matrix Printer Optional |
|
Interaction Method |
Touch Screen & Rotary Encoder |
|
Operating Temperature |
(-10～50) ℃ |
|
Operating Humidity |
(0~95) % (Non-Condensing) |
